Biological Identification
IPT240-V2
Dual Lens 2M USB Camera module
Specification
| Module Size | 88.4 x 20.8 x 8.0MM | |
| Sensor Type | 1/2.7inch | 1/2.7inch |
| Pixel Size | 3.0um x 3.0um | |
| Active Array Size | 1928 x 1088 | 1920 x 1080 |
| Lens Filter | 650±10nm | 850±10nm |
| Shutter Type | Rolling Shutter | |
| Frame Rate | 1080p: 30 fps | 1080p: 30 fps 720p: 60 fps |
| Dynamic Range | 85dB | 72dB |
| S/N ratio | 41dB | 38.,6dB |
| Power | DC 5.0V | |
| Picture format | YUV/MJPEG | |
| Interface type | USB2.0 (driver-free, plug and play) | |
| FOV | 73.1° (support 10°-200°) | |
| Support OS | Windows XP/Vista/Win7/Win8/win10 Linux/ Max-OS with UVC. |
|
| Focus mode | Fixed Focus | |
| Operating temp. | -20°C-70°C | |
| Application | Biometric identification, liveness detection, access control vision machines, face recognition, machines for identification robot navigation, and object recognition. | |
-
